1. Output variables:
• Mass and volume flow
• Net product content/flow
• Temperature
• Density
• Concentration
2. Local Display panel: Standard user interface with 2-line LCD display
• Two optical buttons for local operation
• Glass or plastic dial options
3. Power supply: AC/DC input automatic switching, automatic identification of power supply voltage
85 to 265 VAC, 50/60 Hz, typical value 6 W, maximum 11 W
•18 to 100 VDC, typical value 6 W, maximum 11 W
• In accordance with EN 61010-1 (IEC61010-1) revised version 2 of the low-voltage equipment Specification 2006/95/EC, installation (overvoltage) Category II, pollution level 2
4. Input/output signal (analog output option)
• Non-intrinsic safety
• One active 4-20 mA output
• One active frequency output
• Frequency output can be configured as discrete output
5. Input/output signal (configurable input/output options)
• Non-intrinsic safety
• One or two active 4-20 mA outputs
• One or two active/passive frequency outputs
• One or two active/passive discrete outputs
• One discrete input
6. Input/output signal (intrinsic safety option)
• Intrinsically safe
• One passive 4-20 mA output
• One passive frequency output
• Frequency output can be configured as discrete output
7. Input/output signals (Foundation fieldbus option)
• Intrinsic safety (or optional non-flammable)
• All the way Foundation fieldbus H1 output
8. Input/output signal (PROFIBUS-PA option)
• Intrinsically safe
• One PROFIBUS-PA output
9. HART/WirelessHART
• The Bell 202 signal is superimposed on the primary milliamp output
•WirelessHART is available via THUM adapter
HART communication is not available for Foundation Fieldbus and PROFIBUS-PA transmitter versions
6. Installation options Field installation
• Integrated mount to high precision F, R or H series sensors
• Split-mounted to any 4-wire or 9-wire high-precision Coriolis sensor
7. Application type
• Continuous process control
• Trade transfer measurement
• Two-phase flow/gas bearing
• Instrument online self-calibration
• SIS certified
8. Hazard certification
• Class I, Zone 1
• Class I, Zone 2
• Zone 1
• Zone 2
1. Adopt integrated installation or split installation to maximize flexibility.
2. Using MVD digital processing technology, it can receive performance diagnosis in pinch applications and air-filled batch applications.
3. It reduces the wiring cost and can be easily and quickly installed.
4. Concentration and net flow measurements are available without additional instrumentation.
5. Obtained SIL2 and SIL3 accreditation and certification for trade handover.
6. Verify the health of the sensor online with true field verification while the process is running and without the use of auxiliary references.
7. With the WirelessHART solution, you can obtain additional diagnostic and process information without additional wiring costs.
8. Robust Class 1 classification/Zone 1 housing and optional local operator interface for easy flow meter operation.
Packaging and Transportation
In order to assure that the goods withstand the rigors of transport and arrive in excellent shape, we make sure they are packed adequately. Every single item has been sealed securely with safeguarding supplies and is appropriate for shipment by either land or air.
Shaaxi ZYY, with over a decade of experience as a supplier of professional instrumentation from leading brands such as Emerson, Rosemount, Yokogawa, Endress+Hauser, Azbil, Fisher, Honeywell, ABB, and Siemens, is dedicated to providing our clients with the highest quality products and solutions. For more product information, quotations, or to discuss your specific requirements, please contact us at lm@zyyinstrument.com. Serving you while assisting you to succeed is a task we are delighted to do.
